Ubiquiti UniFi Building-to-Building Bridge XG

hodnotit
30 682 CZK 25 357 CZK bez DPH

Unknown availability

Kód: NAAUBT1149 PN: UBB-XG Záruka: 26 months
Výrobce: UBIQUITI
Ubiquiti UniFi UBB XG 60 GHz wireless bridge with a 10 Gbps SFP+ interface Overview The UniFi Building-to-Building Bridge XG (UBB XG) is a 60 GHz Point-to-Point link that creates short-range, highthroughput connections... více
Počet:
Přidat do košíku

Oblíbené
Porovnat
Tisknout
Poslat známému
Ubiquiti UniFi UBB XG

60 GHz wireless bridge with a 10 Gbps SFP+ interface

Overview
The UniFi Building-to-Building Bridge XG (UBB XG) is a 60 GHz Point-to-Point link that creates short-range, highthroughput connections while also sustaining blazing-fast speed across distances up to 500 m. Designed for plugand-play simplicity, the UBB XG’s bridging units come pre-paired out of the box and both feature calibration LEDs that help you easily adjusttheir angle and postion to optimize signal transmission. Seamlessly integrated with the UniFi Network application, the UBB XG can be set up in minutes and managed from a central, intuitive interface, making network bridging easier than ever!

  • Low-Interference 60 GHz Radio Band
  • 5 GHz backup radio
  • 6 Gbps throughput rate (866.6 Mbps backup)
  • 10G SFP+ port
  • Additional GbE RJ-45 port with PoE++
  • Integrated outer diameter alignment LED for easy setup

SPECIFICATIONS

Operating frequency: 60 GHz (operational 57-66 GHz), 5 GHz backup
Maximum throughput: 6 Gbps
Networking interfaces: 1x GbE RJ-45, 1x 1/10G SFP+
Radio Power (TX): 33 dBm
Antenna gain: 22 dBi (14 dBi for 5GHz antenna)
PoE support: yes, 802.3bt or passive 48 V (±10 %)
Enclosure Materials: Aluminum alloy, UV-resistant polycarbonate
Dimensions: 191,8 x 191,8 x 59 mm
Weight: 1.7 kg (2.9 kg with mount)

Package Contents:
UniFi Building Bridge XG (x2)
Pole mount (x2)
PoE (48 V, 0.65 A) adapter
Power cord (x2)

Manual:
https://dl.ui.com/qig/ubb-xg

Datasheet:
https://dl.ui.com/ds/ubb-xg_ds.pdf

Brand
Type specification :  Client Device
Manufacturer :  UBIQUITI
Technical specification
Management :  yes
PoE-in :  802.3af
Outdoor use :  yes
Indoor use :  no
Max. operating temperature (°C) :  55
Data Rate (Mbps) :  6000 (60GHz), 866,6 (5GHz)
Min. operating temperature (°C) :  -40
Placement :  Pole
Ingress protection :  IPX6
Gain (dBi) :  14
Display
Display :  no
Network interfaces
Wi-Fi frequency :  5 GHz
Wi-Fi frequency :  60 GHz
Gigabit LAN :  yes
LAN :  yes
Max. output power (dBm) :  40
Standards :  802.11ad/ay, 802.11ac, 802.3bt
Operation mode :  PtP (Point-to-Point)
AP mode :  no
Bridge mode :  yes
Client mode :  no
Repeater mode :  no
Router mode :  no
Port Speed :  1 Gb/s + 10 Gb/s
Standard Wi-Fi :  802.11ad/ay
Standard Wi-Fi :  802.11ac
Encryption :  WPA2-AES
Wi-Fi :  yes
WEP security :  no
WPA security :  no
WPA2 security :  yes
WPA3 security :  no
Inputs and outputs
RJ-45 :  1
Interface :  LAN, SFP+, Wi-Fi, Bluetooth
Output to Ext. antenna :  no
Power supply
Input voltage (V) :  48 (DC)
PoE support :  yes
Power consumption - typical (W) :  31.2
Power type :  PoE active (802.3af)
Warranty
Warranty period EU (months) :  26
Warranty period CRN (months) :  26
Physical properties
Color :  white - blue
Depth (mm) :  59
Weight (g) :  1700
Weight (kg) :  1.7
Dimensions :  191,8 × 191,8 × 59 mm
Width (mm) :  191.8
Weight category :  Lightweight - up to 2 kg
Height (mm) :  191.8
Additional equipment and features
LED indication :  yes
Certification mark :  FCC, IC, CE, Terragraph
