Teltonika RUT200 Industrial Router 1x LAN, 1x WAN, 1x SIM + eSIM, LTE, Wi-Fi 4

2 881 CZK 2 381 CZK without VAT

In stock To send

Code: NARTEL0079 PN: RUT200310000 Warranty: 26 months
Výrobce: TELTONIKA
 (UAB Teltonika Networks)
K. Baršausko st. 66, LT-51436, Kaunas Litva
mantas.liutkevicius@teltonika.lt
www.teltonika-networks.com
Teltonika RUT200 Compact industrial router for reliable mobile connectivity in demanding conditions. The RUT200 router is designed for industrial applications... more

Teltonika RUT200

Compact industrial router for reliable mobile connectivity in demanding conditions.

The RUT200 router is designed for industrial applications requiring stable 4G LTE connectivity with speeds up to 150 Mbps download and 50 Mbps upload. The device also supports 3G and 2G networks for maximum coverage. Thanks to its compact dimensions of 83 × 74 × 25 mm and weight of only 125 g, it is easy to install in cabinets or on a DIN rail.

Teltonika RUT200

The device offers two 10/100 Mbps Ethernet ports (1× WAN configurable as LAN, 1× LAN) and Wi-Fi 802.11b/g/n supporting up to 50 concurrent connections. The aluminum housing with plastic panels ensures durability in extreme temperatures from -40 °C to +75 °C. The router is equipped with digital input and output for industrial automation and remote management via the RMS (Remote Management System) platform.

  • 4G LTE Cat 4 mobile connectivity with speeds up to 150/50 Mbps, backward compatible with 3G and 2G networks
  • Automatic backup connection (WAN Failover) with switching between mobile network, Wi-Fi and Ethernet
  • Advanced VPN protocols: OpenVPN, IPsec, GRE, PPTP, L2TP, WireGuard, ZeroTier and more
  • Industrial I/O: 1× digital input (0–30 V) and 1× digital output (max. 30 V, 300 mA)
  • Remote management via RMS with bulk firmware update and configuration capabilities
  • Extreme operating temperature range -40 to +75 °C for demanding environments
  • Flexible power supply 9–30 V DC including passive PoE support via LAN port
  • Hotspot function with captive portal, RADIUS authentication and SMS authorization
  • DIN rail, wall or flat surface mounting (all variants require additional accessories)

Network features and security
The router supports dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP), QoS for traffic prioritization and VLAN for network segmentation. The firewall offers protection against DDoS attacks (SYN flood, SSH/HTTP attacks) and port scan prevention. Advanced authentication via TACACS+ and RADIUS is also available.

Industrial protocols
The device supports industrial protocols MODBUS TCP (server/client), OPC UA (client/server) and DNP3 (station/outstation) for integration into automation systems. Data can be sent via HTTP(S), MQTT or Azure MQTT to cloud platforms including AWS IoT Core, Azure IoT Hub and ThingWorx.

SIM management
The router features an external SIM slot (2FF) and eSIM support with storage for up to 7 profiles. Automatic switching between SIM cards based on signal quality, data limit or roaming ensures uninterrupted connectivity.

Package contents
RUT200, power adapter (9 W), 2× mobile SMA antenna, 1× Wi-Fi antenna (swivel, RP-SMA male), manual.

BASIC SPECIFICATIONS

Mobile connectivity: 4G LTE Cat 4 (150/50 Mbps), 3G (21/5.76 Mbps), 2G (236.8 kbps)
Processor: Mediatek 580 MHz, MIPS 24KEc
Memory: 128 MB RAM, 16 MB Flash
Ethernet: 2× RJ-45 10/100 Mbps (1× WAN, 1× LAN)
Wi-Fi: IEEE 802.11b/g/n, Access Point/Station, up to 50 clients
SIM: 1× external 2FF slot + eSIM (up to 7 profiles)
I/O: 1× digital input (0–30 V), 1× digital output (max. 30 V, 300 mA)
Power supply: 9–30 V DC, 4-pin connector, passive PoE
Power consumption: max. 6.5 W
Operating temperature: -40 to +75 °C
Dimensions: 83 × 74 × 25 mm
Weight: 125 g
Mounting: DIN rail, wall, flat surface (requires mounting kit)
Certifications: CE, UKCA, RCM, EAC, RoHS, REACH, E-mark

Brand
Type specification :  Router
Manufacturer :  TELTONIKA
Technical specification
Ethernet (Mbps) :  100
LTE/4G/5G (Mbps) :  150
Mobilní připojení :  SIM slot
NAND (MB) :  16
Outdoor use :  no
Indoor use :  yes
Max. operating temperature (°C) :  75
Min. operating temperature (°C) :  -40
Placement :  desktop
Industrial design :  yes
Data Rate (Mbps) :  150 (LTE)
Ingress protection :  IP30
VPN :  yes
Gain (dBi) :  5 (Wi-Fi), 3 (LTE)
Memory
Memory size (MB) :  128
Display
Display :  no
Communication
3G support :  yes
4G/LTE support :  yes
5G support :  no
Wi-Fi :  yes
Wi-Fi Standard :  802.11b/g/n
Network interfaces
Wi-Fi frequency :  2400 MHz
Gigabit LAN :  no
LAN :  yes
Standards :  802.11b/g/n, 802.11e, 802.3, 802.3u
Operation mode :  AP, STA
Port Speed :  100 Mb/s
Encryption :  WPA2-Enterprise: PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, EAP-TLS
Wi-Fi :  yes
WEP security :  no
WPA security :  yes
WPA2 security :  yes
WPA3 security :  yes
Antenna
Connectable antennas :  3
Antenna type :  detachable
Inputs and outputs
Connector :  2× RJ-45, 1× SIM, 1× 4pin
RJ-45 :  2
Interface :  LAN, WAN, Wi-Fi, 2G, 3G, 4G/LTE
Output to ext. antenna :  yes
Power supply
Input voltage (V) :  9 - 30 (DC)
Max. Voltage (jack) (V) :  30
Min. Voltage (jack) (V) :  9
PoE support :  yes
Power consumption - typical (W) :  6.5
Input Voltage (V) :  9 - 30 (DC)
Operating system
Operating system :  RutOS
Support
Podpora eSIM :  yes
SIM slot :  yes
Security
Default IP :  192.168.1.1
Physical properties
Color :  black
Weight (g) :  125
Weight (kg) :  0.125
Dimensions :  83 × 74 × 25 mm
Additional equipment and features
LED indication :  yes
Warranty
Warranty period EU (months) :  26
Warranty period CRN (months) :  26
Hodnocení můžou přidávat pouze přihlášení uživatelé a ti kteří produkt zakoupili
