Teltonika TSW202 industrial L2 managed switch 8x port PoE+, 2x SFP

Add recension
3 910 CZK 3 231 CZK without VAT

Unknown availability

Code: NARTEL0033 PN: TSW202000000 Warranty: 26 months
Výrobce: TELTONIKA
Teltonika TSW202 Industrial gigabit L2+ managed switch with eight RJ-45 PoE+ ports and two SFP ports. The total PoE budget is 240 W (max. 30 W per port). It features selected L3 functions, such as static routing for IPv4... more
Count:
Add to Cart

Favorites
Compare
Print
Send to friend
Teltonika TSW202

Industrial gigabit L2+ managed switch with eight RJ-45 PoE+ ports and two SFP ports. The total PoE budget is 240 W (max. 30 W per port). It features selected L3 functions, such as static routing for IPv4 and IPv6 or DHCPv6 client. It also supports a wide range of industrial protocols, including EtherNet/IP, Profinet, and MRP. The switch has a built-in DIN rail mount.
The switching capacity reaches up to 20 Gbps. It has a 512 KB buffer, 8K MAC address table, and supports Jumbo frames up to 10 KB.

  • Managed gigabit L2 switch with L3 features for better management and control.
  • 8-port PoE+ switch with two SFP ports for optical communication.
  • Supports Profinet for automated data processing along with other protocols, such as EtherNet/IP and MRP.
  • Teltonika Networks operating system for switches (TSWOS), intuitively designed for unlimited configuration.

For more information, refer to the attached manual in the documents tab or visit wiki.teltonika-networks.com/view/TSW202.

BASIC SPECIFICATIONS

Number of Ports: 8× RJ-45 10/100/1000 Mb/s, 2× SFP
PoE: Yes, 802.3af/at, budget 240 W (up to 30 W per port)
Switch Capacity: 20 Gbps
Power Supply: DC 7–57 V (power adapter not included in the package)
Dimensions: 132 × 122.2 × 44.2 mm

Brand
Type specification :  Switch
Manufacturer :  TELTONIKA
Technical specification
Management :  yes
OSI layer :  L3 static (L2+)
Fanless :  yes
Switching capacity (Gbps) :  20
IPv6 support :  ano
Homologation EN50155 :  no
PoE-in :  ne
PoE-out :  802.3af/at
PoE-out (quantity) :  8
Outdoor use :  no
Max. operating temperature (°C) :  75
Min. operating temperature (°C) :  -40
Placement :  DIN rail mounting
Ingress protection :  IP30
Stackable :  ne
Display
Display :  no
Network interfaces
Gigabit LAN :  yes
Port Speed :  1 Gb/s
Inputs and outputs
RJ-45 :  8
RS-232 port :  no
SFP :  2
Card reader
MicroSD card support :  no
Power supply
PoE support :  yes
Power type :  external power adapter
Input Voltage (V) :  7 - 57 (DC)
Warranty
Warranty period EU (months) :  26
Warranty period CRN (months) :  26
Physical properties
Color :  black
Weight (g) :  610
Dimensions :  132 × 122,2 × 44,2 mm
Weight category :  Lightweight - up to 2 kg
Additional equipment and features
Certification mark :  CE, CB, RCM, FCC, IC, EAC, UCRF
